Wireless Gaming Headset with 3D SoundRF-GUV1202User Guide

10Using the wireless receiverYou can clip the wireless receiver to your belt, pocket, or sleeve for convenient usage.MUTE

11RF-GUV1202Connecting to a PlayStation 3 (PS3)You can connect your headset to your PS3 in a variety of ways to receive PS3 audio:• AV cable or TV hea

122 Choose your connection method.If you want to connect the audio using a headphone jack on a TV, monitor, or receiver, complete the instructions in

13RF-GUV1202Option B: AV cable connection methodStep 3 (continued)Make the connections shown in the following illustration.4 Turn on your PS3, then op

146 Select Audio Input Connector / SCART / AV Multi to send the PS3 audio to your headset.7 Press X to save the setting.8 Press the POWER button on th

15RF-GUV1202Using an HDMI connection with a headphone jack or AV cableNote: Connecting to a headphone jack is the easiest connection method.When your

162 Choose your connection method.If you want to connect the audio using a headphone jack on a TV, monitor, or receiver, complete the instructions in

17RF-GUV1202Option B: AV cable connection methodStep 3 (continued)Make the connections shown in the following illustration.4 Turn on your PS3, then op

186 Press the POWER button on the wireless transmitter, then press the POWER button on the wireless receiver. When the transmitter is connected to the

19RF-GUV1202Connecting to an Xbox 360Using a headphone jack or AV cableTo connect to an Xbox 360 using a headphone jack or AV cable:1 Plug the microph

2Wireless Gaming Headset with 3D SoundContentsImportant safety instructions ...

202 Choose your connection method.If you want to connect the audio using a headphone jack on a TV, monitor, or receiver, complete the instructions in

21RF-GUV1202Option B: AV cable connection methodStep 3 (continued)Make the connections shown in the following illustration.4 Press the POWER button on

22Using an HDMI connection with a headphone jack or audio adapterNote: Connecting to a headphone jack is the easiest connection method.When your Xbox

23RF-GUV12022 Choose your connection method.If you want to connect the audio using a headphone jack on a TV, monitor, or receiver, complete the instru

24Option B: HDMI audio adapter connection methodMake the connections shown in the following illustration.4 Press the POWER button on the wireless tran

25RF-GUV1202Connecting a computerIf your computer has a Windows operating system, go to “Windows 7, Windows Vista, or Windows XP” on page 25.If your c

262 Make the connections shown in the following illustration.3 Click Start, Control Panel, then click the icon that controls sound and audio devices.

27RF-GUV12024 Click the Playback tab.5 Make a note of the default devices selected in the Sound Playback and Sound Recording lists. If you do not want

2812 Open the Sounds and Audio Devices Properties box again.13 In the Sound Recording list, select Rocketfish Wireless Headset, then click the Volume

29RF-GUV1202Mac OS X v10.2.8 and aboveTo connect to a Mac-based computer:1 Plug the microphone into the left or right MIC jack on your headset. Twist

3RF-GUV1202Important safety instructions1 Read these instructions.2 Keep these instructions.3 Heed all warnings.4 Follow all instructions.5 Do not use

302 Make the connections shown in the following illustration.3 Click the Apple® menu icon and go to System Preferences/Sound.4 Select the Output tab a

31RF-GUV12029 Press the POWER button on the wireless transmitter, then press the POWER button on the wireless receiver. When the transmitter is connec

32TroubleshootingSpecificationsProblem SolutionNo audio • Make sure that the volume is not turned down or muted.• Press the ALL MUTE button on the lef

33RF-GUV1202Legal noticesFCC Part 15This device complies with Part 15 of the FCC Rules. Operation of this product is subject to the following two cond

34One-year limited warrantyRocketfish Products (“Rocketfish”) warrants to you, the original purchaser of this new product (“Product”), that the Produc

35RF-GUV1202What does the warranty not cover?This warranty does not cover:• Customer instruction• Installation•Set up adjustments•Cosmetic damage• Dam

11-1091ENGLISHwww.rocketfishproducts.com (800) 620-2790Distributed by Best Buy Purchasing, LLC7601 Penn Avenue South, Richfield, MN 55423-364

4Features• Compatible with:• PlayStation®3 (PS3™)• Xbox 360® and Xbox LIVE®• PC running Windows® 7, Windows Vista®, or Windows® XP• Mac® computer runn

5RF-GUV1202Package contentsNote: If your Xbox 360 is connected to a TV or monitor using an HDMI cable, you may need the Microsoft HDMI audio adapter (

6Wireless transmitterNote: When you turn on the wireless transmitter and receiver, they pair automatically.# Component Description1POWER button Press

7RF-GUV1202Wireless receiverNote: When you turn on the wireless transmitter and receiver, they pair automatically.# Component Description1Reset button

8Headset jacks and controls# Component Description1Right microphone jack (MIC)Plug the microphone into this jack.2Left microphone jack (MIC)Plug the m

9RF-GUV1202Installing the wireless receiver batteriesTo install the wireless receiver batteries:1 Press the release button on the back of the receiver
